LTE MILENAGE Test (U)SIM Card – Mini-UICC

Test sim card is used to produce Mobile phone and Development of Technologies for
Cellular phone.

We cardmfg.com have contniued to evolve and expand, maintaining our premier position in the test sim card industry part.

Test sim(usim) card is used to test various GSM,CDMA,WCDMA,HSDP+.2G,USIM,3G,4G,NFC.
etc cellular phones.

Mobile-phone test sim card introduction
1. The capacity of chip : 8K, 16K, 32K, 64K, 72K,128K, 144K,256K, 1G etc.
2. Purpose : mobile-phone test and other related industry.
3. Application range : GSM,2G, CDMA,3G(WCDMA),HSDP, NFC ,4G etc.

LTE USIM Card Support CDMA ,GSM ,WCDMA ,TD_SCDMA Network all data .

GSM 3G WCDMA LTE 4G NFC CSIM SIM CARD

LTE USIM Card can write ” PIN,PUK ,ADM , IMSI ,ICCID ,SMSC, OPC ,KI ” into card .



compliant to 3GPP standard , Can operate at a max  temperature  75c , minimum temperature of -40c .





  • UICC multi-application platform
  • New LTE data fields implemented
  • Three applications: Test SIM, Test USIM, Test ISIM
  • 1.8V/3V / 5V
  • 128K EEPROM
  • APIN 1 disabled
  • MILENAGE algorithm
  • Creation of new data fields allowed
  • Mini-UICC: the 3rd Form Factor (3FF) – half the size compared to the Plug-IN card
  • Repluggable card







LTE 4G Series is designed to meet the current market demands rapid development of the fourth generation of mobile communication, according to domestic and foreign carriers to promote the use of 4G networks, independent research and development of new smart card products for TD-LTE and FDD LTE and other network. In terms of compatibility, it applies not only to the 4G network, but also backward compatible with 3G, 2G network, can successfully adapt to the transition from the era of 3G to 4G market era.

LTE USIM NATIVE and JAVA including two series, capacity from 64k to 256k covering all product types to meet various needs of domestic and international markets.

Main Features
Chip Features
  • Voltage range : 1.62V~5.5V
  • Data Retention : Minimum of 10 years
  • Endurance(Read/Write) : Minimum of 100,000 cycles
Function Support
  • Remote File Management
  • Remote Application Management
  • BIP
  • MMS
Security Features
  • Milenage
  • Authentication counter
  • DES/3DES
  • AES
Value-added Services
  • All IOD Service
  • Super Phonebook
  • Group SMS
  • Smart Roaming
  • ……
 Standards compliance


  • ISO 7816-1, 7816-2, 7816-3, ISO7816-4
  • GSM 11.11, GSM 11.14, GSM 11.17, GSM 03.40, GSM 03.48
  • 3GPP TS 31.101, 3GPP TS 31.102, 3GPP TS 31.114, 3GPP TS 43.109
  • WAP Wireless Identity Module Specification
  • Celltick v14
  • ETSI TS 102 221
  • ETSI TS 102 222
  • ETSI TS 102 223
  • ETSI TS 102 224
  • ETSI TS 102 225
  • ETSI TS 102 226
  • ETSI TS 102 241



GSM 3G WCDMA LTE 4G NFC CSIM SIM CARD

Packing and Shipping





1. 200pcs /box ,  2000pcs ,3000pcs ,5000pcs /carton ,  carton is paper carton



2. Shipping :  By express, by air or  sea



3. Weight :7Kg /1000pcs
